EM3A-15ALB224
- Servo motor with a power rating of 5kW to pair only with Estun Drive.
- Low Inertia: Provides a quick response for High Dynamic Loads
- 23bit Absolute /Incremental Encoder feedback
- Insulation Class F with Self Cooling
- Suitable for applications requires speeds up to 5000 rpm
- Without Electro-Mechanical Brake and standard Oil seal
- Small Flange and shaft sizes with high TorqueIP65 rated
This product is available & ready to ship.
15
People watching this product now!
Description
EM3A-15ALB224 is a 1.5KW Rotary Servo Motor with small size, High speed (3000 rpm rate/ 5000 rpm max) with 17bit abs/Inc feedback and low inertia that provides high Dynamic for Frequently Start/Stop load requirement with Fast Accel/Decel.
Specification
 Motor MODEL: EM3A-15ALB224 |
||
| Flange [mm] | 100 | |
| Rated power [kW] | 1.5 | |
| Rated speed[r/min] | 3000 | |
| Maximum speed [r/min] | 5000 | |
| Rated torque [N.m] | 4.78 | |
| Maximum torque [N.m] | 14.3 | |
| Rated Voltage [V] | 200 | |
| Rated current [Arms] | 9.5 | |
| Maximum current [Arms] | 31.6 | |
| Motor inertia [ kg. ] | 2.33 | |
| Allowable shaft end load | Radial[N] | 686 |
| Axial[N] | 196 | |
| Holding torque [N.m] | ≥8 | |
| Motor Weight [kg] | 5.1 | |
| Motor Packing Weight[kg] | 5.8 | |
| Motor Box Dimensions [mm] | 372 x 199 x 142 | |
Torque/Speed Curve
| Rated Power (W) |
1500 |
|---|---|
| Rated Voltage (V) |
200 |
| Rated / Max Speed (rpm) |
3000 / 5000 |
| Rated / Max Torque (N.M) |
4.78 / 14.30 |
| Flange / Shaft Size (mm) |
100 / 24 |
| Feedback Type |
23bit abs |
| Brake |
No |
