EM3A-08ALA248
- Servo motor with a power rating of 750W to pair only with Estun Drive.
- Low Inertia: Provides a quick response for High Dynamic Loads
- 23bit Absolute /Incremental Encoder feedback
- Insulation Class F with Self Cooling
- Suitable for applications requires speeds up to 6000 rpm
- With Electro-Mechanical Brake and standard Oil seal
- Small Flange and shaft sizes with high Torque
- IP65 rated
This product is available & ready to ship.
11
People watching this product now!
Description
EM3A-08ALA248 is a 750W Rotary Servo Motor with brake but small size, High speed (3000 rpm rate/ 6000 rpm max) with 23bit abs/Inc feedback and low inertia that provides high Dynamic for Frequently Start/Stop load requirement with Fast Accel/Decel.
Specification
 Motor MODEL: EM3A-08ALA248 |
||
| Flange [mm] | 80 | |
| Rated power [kW] | 0.75 | |
| Rated speed[r/min] | 3000 | |
| Maximum speed [r/min] | 6000 | |
| Rated torque [N.m] | 2.39 | |
| Maximum torque [N.m] | 8.37 | |
| Rated Voltage [V] | 200 | |
| Rated current [Arms] | 5.1 | |
| Maximum current [Arms] | 19.5 | |
| Motor inertia [ kg. ] | 1.07 | |
| Allowable shaft end load | Radial[N] | 392 |
| Axial[N] | 147 | |
| Holding torque [N.m] | ≥3.2 | |
| Motor Weight [kg] | 3.2 | |
| Motor Packing Weight[kg] | 3.5 | |
| Motor Box Dimensions [mm] | 302 x 152 x 105 | |
Torque/Speed Curve
| Rated Power (W) |
750 |
|---|---|
| Rated Voltage (V) |
200 |
| Rated / Max Speed (rpm) |
3000 / 6000 |
| Rated / Max Torque (N.M) |
2.39 / 8.37 |
| Flange / Shaft Size (mm) |
80 / 19 |
| Feedback Type |
23bit abs |
| Brake |
Yes |
