EM3A-01ATA222
- Servo motor with a power rating of 100W to pair only with Estun Drive.
- Low Inertia: Provides a quick response for High Dynamic Loads
- 17bit Absolute /Incremental Encoder feedback
- Insulation Class F with Self Cooling
- Suitable for applications requires speeds up to 6000 rpm
- Without Electro-Mechanical Brake and standard Oil seal
- Small Flange and shaft sizes with high Torque
- IP65 rated
This product is available & ready to ship.
14
People watching this product now!
Description
EM3A-01ATA222 is a 100W Rotary Servo Motor with Small size, High speed (3000 rpm rate/ 6000 rpm max) with 17bit abs/Inc feedback and low inertia that provides high Dynamic for Frequently Start/Stop load requirement with Fast Accel/Decel.
Specification
 Motor MODEL: EM3A-01ATA222 |
||
| Flange [mm] | 40 | |
| Rated power [kW] | 0.1 | |
| Rated speed[r/min] | 3000 | |
| Maximum speed [r/min] | 6000 | |
| Rated torque [N.m] | 0.318 | |
| Maximum torque [N.m] | 0.954 | |
| Rated Voltage [V] | 200 | |
| Rated current [Arms] | 1.1 | |
| Maximum current [Arms] | 3.5 | |
| Motor inertia [ kg. ] | 0.0428 | |
| Allowable shaft end load | Radial[N] | 78 |
| Axial[N] | 54 | |
| Holding torque [N.m] | ≥0.32 | |
| Motor Weight [kg] | 0.5 | |
| Motor Packing Weight [kg] | 0.8 | |
| Motor Box Dimensions [mm] | 182 x 107 x 65 | |
Torque/Speed Curve
| Rated Power (W) |
100 |
|---|---|
| Rated Voltage (V) |
200 |
| Rated / Max Speed (rpm) |
3000 / 6000 |
| Rated / Max Torque (N.M) |
0.318 / 0.954 |
| Flange / Shaft Size (mm) |
40 / 8 |
| Feedback Type |
17bit abs |
| Brake |
No |
